IQXO-540 Clock Oscillator

Description

Standard  2.0 x 1.6  mm crystal oscillator hermetically sealed ceramic package.

Package

2.0 x 1.6 x 0.8 mm

Frequency 1.0 to 80.0 MHz
Frequency Stability ±50.00ppm to ±100.00ppm
Ageing ±5ppm max per year @ 25°C
Operating Temp Range

-20 to 70°C ,-40 to 85°C

Supply Voltage 3.3 V
Output Compatibility CMOS
Drive Capability 15pF max

 Part numbers available in the IQXO-540 model:

IQD Part No Frequency Frequency Stability Operating Temperature Voltage Applications Reference
LFSPXO068250 38.4 MHz ±50ppm -40°C to 85°C 3.3 V 3G/4G/5G, Audio, Small Cell, UART 831068250
LFSPXO056240 19.44 MHz ±50ppm -40°C to 85°C 3.3 V Bluetooth 831056240
LFSPXO056245 26 MHz ±50ppm -40°C to 85°C 3.3 V CAN, Bluetooth, GPS, Small Cell 831056245
LFSPXO082153 26 MHz ±25ppm -20°C to 70°C

3.3 V

CAN, Bluetooth, GPS, Small Cell

830208215309

LFSPXO082146 4 MHz ±25ppm -20°C to 70°C 3.3 V CAN, Processor

830208214609

LFSPXO054046 10 MHz ±50ppm -40°C to 85°C 3.3 V Processor, Ethernet 831054046
