Disciplined or GPS Oven Controlled Crystal Oscillators

Disciplined OCXOs

Disciplined or GPS Oven Controlled Crystal Oscillators

GNSS Disciplined OCXOs (aka GNSSDO, GPSDO, GPS clocks or DOs), are advanced clock modules which provide electrical timing functionality for distributed network systems. They combine an OCXO with a software algorithm to provide 1pps (pulse per second) timing synchronization based on the signal received from GNSS satellite systems.

Disciplined OCXOs offer a highly reliable failsafe signal after loss of lock to the GNSS signal caused by interruptions due to bad weather, jamming or loss of view of enough constellation satellites as they exhibit a holdover capability.

This holdover function guarantees a continuous 1pps signal until GNSS is restored giving reassurance and reliability of continuous signal and synchronization so critical to many applications, including PNT, 4G/5G base stations, IP backhaul, clock servers, PTP servers, smart power grids, Transparent Clocks and MiFID II Compliance during GNSS outage.

IQD’s disciplined OCXOs are LTE compatible and are available with or without a GPS receiver.

What is Holdover?

IQD Category DOCXO Square

Key Features of Disciplined OCXO

  • Frequency stability as tight as ±0.20ppb
  • Package sizes IQD offers: from 20.2 x 20.2 mm
  • Operating temperature -20°C to 85°C
  • Best Holdover ±1µs/24 hours

Applications for Disciplined OCXOs

IQD's disciplined OCXOs are used in applications including:

  • PNT systems
  • 4G and 5G base stations
  • IP backhaul
  • Clock servers and PTP servers
  • Smart power grids
  • Transparent Clocks
  • Applications requiring MiFID II compliance during GNSS outages

Featured Products and applications

IQCM-112 – Supersonic spaceplane, Isolated Timing Synchronization, Smart Grids, 4G/5G Base stations

IQCM-160 – Geophysical Survey, RF/MW Components, base stations of 4G/5G telecom

IQCM-200 - GPS denial protection, WAN-time receiver



Learn more about other frequency products from IQD...

FAQs | Disciplined OCXOs

What is a GNSS-disciplined OCXO?

A GNSS-disciplined OCXO, or GNSSDO, combines an OCXO and a software algorithm to provide a 1 PPS timing signal synchronised to a GNSS satellite signal.

What does holdover mean in a disciplined OCXO?

Holdover is the capability to provide a timing signal after the module loses lock to GNSS.  IQD disciplined OCXOs provide a continuous 1 PPS signal until GNSS can be restored.

What are GNSS-disciplined OCXOs used for?

Suitable applications for IQD disciplined OCXOs include PNT, 4G/5G base stations, IP backhaul, clock and PTP servers, smart power grids and Transparent Clocks.
